Valpadana 1540

Production
Manufacturer:	Valpadana
Factory:	San Martino, Italy

Valpadana 1540 Power
Engine:	35.5 hp 26.5 kW
PTO (claimed):	32 hp 23.9 kW

Mechanical
Chassis:	4x4 MFWD 4WD
Brakes:	Wet disc
Cab:	cab with heat optional
Transmissions:	12-speed
16-speed

Hydraulics
Pressure:	1595 psi 110.0 bar
Valves:	2 rear standard
3 rear + 1 front optional
Pump flow:	7.4 gpm 28.0 lpm
Total flow:	12.6 gpm 47.7 lpm
Steering flow:	5.2 gpm 19.7 lpm

Tractor hitch
Rear Type:	I
Rear lift:	2,646 lbs 1200 kg
Front Hitch:	IN optional
Front lift:	881.8 lbs 399 kg

Power Take-off (PTO)
Rear RPM:	540/750
Front PTO:	optional
Front RPM:	1000

Engine Detail
3TNV88-KLAN
diesel
3-cylinder
liquid-cooled
Displacement:	100.2 ci 1.6 L
Bore/Stroke:	3.465x3.543 inches 88 x 90 mm
Power:	35.5 hp 26.5 kW
Air cleaner:	dry
Rated RPM:	2800
Torque:	80 lb-ft 108.5 Nm
Torque RPM:	1200

Dimensions
Wheelbase:	67 inches 170 cm
Length:	130 inches 330 cm
Width:	51 inches 129 cm
Height:	83.1 inches 211 cm
Weight:	3,527 lbs 1599 kg
Ground clearance:	13.4 inches 34 cm
