Valmet 903

Production: 1979 - 1983

Production
Manufacturer:	Valmet
Type:	Row-Crop tractor

Valmet 903 Power
Engine:	95.2 hp 71.0 kW
PTO (claimed):	91.2 hp 68.0 kW

Mechanical
Chassis:	4x2 2WD
4x4 MFWD 4WD
Differential lock:	mechanical rear
Steering:	power
Brakes:	disc
Cab:	Cab standard with heater.
Transmission:	16-speed

Capacity
Fuel:	23.8 gal 90.1 L
Hydraulic system:	6.1 gal 23.1 L

Hydraulics
Capacity:	6.1 gal 23.1 L
Pressure:	3046 psi 210.0 bar
Pump flow:	9.2 gpm 34.8 lpm

Tractor hitch
Rear lift:	6393 lbs 2899 kg

Power Take-off (PTO)
Rear PTO:	independent
Rear RPM:	540 (1.375)
Engine RPM:	540@1556

Electrical
Ground:	negative
Battery volts:	12
Battery AH:	130

Engine Detail
Valmet 411 CS
turbocharged diesel
4-cylinder
liquid-cooled
Displacement:	268.5 ci 4.4 L
Bore/Stroke:	4.25x4.72 inches 108 x 120 mm
Power:	95.2 hp 71.0 kW
Rated RPM:	2200
Torque:	247.1 lb-ft 335.1 Nm
Torque RPM:	1500
Starter:	electric
Starter volts:	12
Oil capacity:	13.7 qts 13.0 L
Coolant capacity:	16.9 qts 16.0 L

Transmission
Transmission:	Hi-Trac
Gears:	16 forward and 4 reverse
Clutch:	310mm disc

Dimensions
2WD Wheelbase:	92.1 inches 233 cm
4WD Wheelbase:	96.3 inches 244 cm
2WD Length:	153.7 inches 390 cm
4WD Length:	164.2 inches 417 cm
2WD Width:	77.6 inches 197 cm
4WD Width:	83.1 inches 211 cm
2WD Weight:	7981 lbs 3620 kg
4WD Weight:	8907 lbs 4040 kg
2WD Ground clearance:	18.9 inches 48 cm
4WD Ground clearance:	18.5 inches 46 cm
