Fendt 411 Vario

Production: 2006 - 2012

Production
Manufacturer:	Fendt (a part of AGCO)
Type:	Row-Crop tractor

Fendt 411 Vario Power
Engine (gross):	112.7 hp 84.0 kW
Engine (net):	99.2 hp 74.0 kW
Engine (max):	118 hp 88.0 kW

Mechanical
Chassis:	4x4 MFWD 4WD
Steering:	power
Brakes:	wet disc
Cab:	Cab standard with heat. Air-conditioning optional.
Transmission:	continuously variable transmission

Hydraulics
Type:	load sensing
Pressure:	2900 psi 200.0 bar
Pump flow:	19.8 gpm 74.9 lpm
29.1 gpm 110.1 lpm *Optional

Tractor hitch
Rear Type:	III/II
Rear lift:	16424 lbs 7449 kg
Front lift:	6834 lbs 3099 kg

Power Take-off (PTO)
Rear PTO:	independent
Rear RPM:	540/540E/1000
Front PTO:	independent*Optional
Front RPM:	540
1000

Electrical
Ground:	negative
Charging system:	alternator
Charging amps:	150
Charging volts:	14
Battery volts:	12
Battery AH:	90

Engine Detail
Deutz
turbocharged intercooled diesel
4-cylinder 16-valve
liquid-cooled
Displacement:	246.4 ci 4.0 L
Bore/Stroke:	3.98x4.96 inches 101 x 126 mm
Rated Power (ECE R24):	99.2 hp 74.0 kW
Rated Power (EC 97/98):	112.7 hp 84.0 kW
Maximum Power (ECE R24):	114 hp 85.0 kW
Maximum Power (EC 97/68):	118 hp 88.0 kW
Rated RPM:	2100
Torque:	372.5 lb-ft 505.1 Nm
Torque RPM:	1400
Starter:	electric
Starter volts:	12

Transmission
Transmission:	Vario
Type:	continuously variable transmission
Gears:	infinite forward and reverse

Dimensions
Wheelbase:	95.2 inches 241 cm
Length:	167.4 inches 425 cm
Width:	92.1 inches 233 cm
Height:	114.2 inches 290 cm
Weight:	11905 lbs 5400 kg
Max weight:	19842 lbs 9000 kg
Ground clearance:	18.2 inches 46 cm
Front tread:	71.7 inches 182 cm
Rear tread:	70.9 inches 180 cm
