Ursus 1734

Production: 2000 - 2009

Production
Manufacturer:	Ursus
Factory:	Warsaw, Poland

Ursus 1734 Power
Engine:	167.6 hp 125.0 kW
PTO (claimed):	146.2 hp 109.0 kW

Mechanical
Chassis:	4x4 MFWD 4WD
Differential lock:	electro-hydraulic front and rear
Steering:	power
Brakes:	wet disc
Cab:	Cab standard with heater. Air-conditioning optional.
Transmission:	16-speed two-speed power shift

Hydraulics
Pump flow:	14.3 gpm 54.1 lpm

Tractor hitch
Rear Type:	III
Control:	position and draft control
Rear lift:	15873 lbs 7199 kg

Power Take-off (PTO)
Rear PTO:	independent
Clutch:	hydraulic
Rear RPM:	540/1000 (1.375)
1000 (1.75)
Engine RPM:	540@1890 1000@1920
Front PTO:	1000*Optional

Electrical
Charging system:	alternator
Charging amps:	55
Charging volts:	14
Batteries:	2
Battery volts:	12
Battery AH:	172

Engine Detail
Zetor Z 8604.000
turbocharged diesel
6-cylinder
liquid-cooled
Displacement:	445.4 ci 7.3 L
Bore/Stroke:	4.33x5.04 inches 110 x 128 mm
Power:	167.6 hp 125.0 kW
Fuel system:	direct injection
Compression:	16.8:1
Rated RPM:	220
Torque:	477.9 lb-ft 648.0 Nm
Torque RPM:	1480
Starter:	electric
Starter volts:	24
Starter power:	9 hp 6.7 kW

Transmission
Type:	two-speed power shift
Gears:	16 forward and 8 reverse
Clutch:	380mm hydraulic dry disc
Four gears (1-4) in two ranges (I/II) plus reverse range (R) with two-speed power shift.

Dimensions
Wheelbase:	106.5 inches 270 cm
Length:	177.2 inches 450 cm
Width:	95.9 inches 243 cm
Height (exhaust):	119.7 inches 304 cm
