Ursus 1934

Production: 2001 - 2009

Production
Manufacturer:	Ursus
Factory:	Warsaw, Poland

Ursus 1934 Power
Engine:	187.7 hp 140.0 kW
PTO (claimed):	166.3 hp 124.0 kW

Mechanical
Chassis:	4x4 MFWD 4WD
Differential lock:	electro-hydraulic front and rear
Steering:	power
Brakes:	wet disc
Cab:	Cab standard with heater. Air-conditioning optional.
Transmission:	16-speed two-speed power shift

Capacity
Fuel:	93.8 gal 355.0 L
Hydraulic system:	14.5 gal 54.9 L

Hydraulics
Capacity:	14.5 gal 54.9 L
Pump flow:	14.5 gpm 54.9 lpm

Tractor hitch
Rear Type:	III
Control:	position and draft control
Rear lift:	15873 lbs 7199 kg

Power Take-off (PTO)
Rear PTO:	independent
Clutch:	hydraulic
Rear RPM:	540/1000 (1.375)
1000 (1.75)
Engine RPM:	540@1890 1000@1920
Front PTO:	1000*Optional

Electrical
Charging system:	alternator
Charging amps:	55
Charging volts:	14
Batteries:	2
Battery volts:	12
Battery AH:	172

Engine Detail
Zetor Z 8604.020
turbocharged intercooled diesel
6-cylinder
liquid-cooled
Displacement:	445.4 ci 7.3 L
Bore/Stroke:	4.33x5.04 inches 110 x 128 mm
Power:	187.7 hp 140.0 kW
Fuel system:	direct injection
Air cleaner:	dual dry element
Compression:	15.6:1
Rated RPM:	220
Torque:	532.5 lb-ft 722.1 Nm
Torque RPM:	1530
Starter:	electric
Starter volts:	24
Starter power:	9 hp 6.7 kW
Oil capacity:	20.1 qts 19.0 L
Coolant capacity:	30.6 qts 29.0 L

Transmission
Type:	two-speed power shift
Gears:	16 forward and 8 reverse
Clutch:	380mm hydraulic dry disc
Oil capacity:	58.1 qts 55.0 L
Four gears (1-4) in two ranges (I/II) plus reverse range (R) with two-speed power shift.

Dimensions
Wheelbase:	106.5 inches 270 cm
Length:	177.2 inches 450 cm
Width:	95.9 inches 243 cm
Height (cab):	118.9 inches 302 cm
Height (exhaust):	119.7 inches 304 cm
Weight:	13625 lbs 6180 kg
Ballasted weight:	17968 lbs 8150 kg
Ground clearance:	19.7 inches 50 cm
Front tread:	66.5/70.5/74.4 inches 168/179/188 cm
Rear tread:	70.9 inches 180 cm
