Shibaura S330

Production: 1989

Production
Manufacturer:	Shibaura
Type:	Compact Utility tractor

Shibaura S330 Power
Engine:	30 hp 22.4 kW

Mechanical
Chassis:	4x2 2WD
4x4 MFWD 4WD
Steering:	power
Brakes:	wet disc
Cab:	Open operator station.
Transmissions:	12-speed
12-speed sync shuttle

Tractor hitch
Rear Type:	I
Control:	position control with available draft control

Power Take-off (PTO)
Rear RPM:	540

Electrical
Ground:	negative
Battery volts:	12

Engine Detail
Shibaura N843
diesel
3-cylinder
liquid-cooled
Displacement:	91.3 ci 1.5 L
Power:	30 hp 22.4 kW
Starter:	electric
Starter volts:	12

Dimensions
Wheelbase:	65 inches 165 cm
Length:	121.3 inches 308 cm
Width:	59.3 inches 150 cm
Height:	81.3 inches 206 cm
2WD Weight:	2436 lbs 1104 kg
4WD Weight:	2635 lbs 1195 kg
2WD Ground clearance:	11.6 inches 29 cm
4WD Ground clearance:	11.2 inches 28 cm
2WD Front tread:	43.5 inches 110 cm
4WD Front tread:	46.1 inches 117 cm
Rear tread:	47.8 inches 121 cm
