Schluter Compact 1150 TV 6

Production: 1983 - 1985

Contents:

Production

Manufacturer:Schluter

Schluter Compact 1150 TV 6 Power

Engine:110 hp 82.0 kW

Mechanical

Chassis:4x4 MFWD 4WD
Steering:hydrostatic power
Brakes:drum
Transmission:12-speed

Hydraulics

Total flow:11.9 gpm 45.0 lpm

Tractor hitch

Rear lift:8,599.5 lbs 3900 kg
11,466 lbs 5200 kg (optional)

Power Take-off (PTO)

Rear RPM:540/1000

Engine Detail

MAN D 0226 MTE 51
turbo diesel
6-cylinder
Displacement:347.0 ci 5.7 L
Bore/Stroke:4.016x4.567 inches 102 x 116 mm
Power:110 hp 82.0 kW
Rated RPM:2200
Torque:315.7 lb-ft 428.1 Nm
Torque RPM:1300

Transmission

Gears:12 forward and 5 reverse

Dimensions

Wheelbase:96.1 inches 244 cm (2WD)
94.5 inches 240 cm (4WD)
Length:164.2 inches 417 cm
Height:106.7 inches 271 cm
Weight:10,848 lbs 4920 kg
