Renault Master 1

Production: 1964 - 1967

Contents:

Production

Manufacturer:Renault

Renault Master 1 Power

Engine:60 hp 44.7 kW

Mechanical

Chassis:4x2 2WD
Steering:mechanical
Brakes:dry disc
Transmission:10-speed

Hydraulics

Total flow:7.1 gpm 26.9 lpm

Tractor hitch

Rear lift:3,528 lbs 1600 kg

Power Take-off (PTO)

Rear RPM:540/ground

Engine Detail

MWM D 308-4
4-cylinder
Displacement:181.7 ci 3.0 L
Bore/Stroke:3.74x4.134 inches 95 x 105 mm
Power:60 hp 44.7 kW
Rated RPM:2500
Torque:140.9 lb-ft 191.1 Nm
Torque RPM:1590

Transmission

Gears:10 forward and 2 reverse

Dimensions

Wheelbase:92.1 inches 233 cm
Length:155.9 inches 395 cm
Height:96.1 inches 244 cm
Weight:6,053 lbs 2745 kg (2WD)
6,880 lbs 3120 kg (4WD)
