New Holland TC29DA

Production: 2004 - 2006

Production
Manufacturer:	New Holland
Type:	Compact Utility tractor
Original price:	$16,500 (2000 )

New Holland TC29DA Power
Engine:	29 hp 21.6 kW
Gear PTO (claimed):	25 hp 18.6 kW
Hydro PTO (claimed):	23.6 hp 17.6 kW

Mechanical
Chassis:	4x4 MFWD 4WD
Steering:	power
Cab:	Two-post foldble ROPS.
Transmissions:	9-speed gear
hydrostatic

Hydraulics
Type:	open center
Pump flow:	7.6 gpm 28.8 lpm
Steering flow:	5.1 gpm 19.3 lpm

Tractor hitch
Rear Type:	I
Rear lift (at ends):	1635 lbs 741 kg

Power Take-off (PTO)
Rear PTO:	live
Rear RPM:	540
Mid PTO:	optional
Mid RPM:	2000

TC29DA Serial Numbers
2004:	G100009
2005:	G103054
2006:	G105497

Electrical
Ground:	negative
Battery volts:	12

Engine Detail
Shibaura J843
diesel
3-cylinder
liquid-cooled
Displacement:	81.2 ci 1.3 L
Bore/Stroke:	3.307x3.15 inches 84 x 80 mm
Power:	29 hp 21.6 kW
Rated RPM:	2800
Starter volts:	12

Dimensions
Wheelbase:	63 inches 160 cm
SuperSteer Wheelbase:	72 inches 182 cm
Length:	106.2 inches 269 cm
SuperSteer Length:	115.3 inches 292 cm
Width:	54.3 inches 137 cm
Height (ROPS):	87.8 inches 223 cm
Weight:	2474 lbs 1122 kg
