New Holland 1925

Production: 1997 - 1999

Production
Distributor:	New Holland
Manufacturer:	Shibaura
Type:	Compact Utility tractor
Original price:	$17,500

New Holland 1925 Power
Engine (gross):	34 hp 25.4 kW
Gear PTO (claimed):	29.1 hp 21.7 kW
Hydro PTO (claimed):	27.3 hp 20.4 kW

Mechanical
Chassis:	4x4 MFWD 4WD
Final drives:	spur gear
Steering:	hydrostatic power
Brakes:	wet disc
Cab:	Two-post fixed ROPS. Foldable ROPS optional.
Transmissions:	9-speed sliding gear
hydrostatic

Hydraulics
Type:	open center
Pressure:	2133 psi 147.1 bar
Pump flow:	6.1 gpm 23.1 lpm
Total flow:	9.6 gpm 36.3 lpm
Steering flow:	3.5 gpm 13.2 lpm

Tractor hitch
Rear Type:	1
Control:	position control
Rear lift (at 24"/610mm):	1,635 lbs 741 kg

Power Take-off (PTO)
Rear PTO:	transmission
live (hydro)
Rear RPM:	540
Mid PTO:	live (hydro)
Mid RPM:	2000

Electrical
Ground:	negative
Battery volts:	12

Engine Detail
Shibaura
diesel
3-cylinder
liquid-cooled
Displacement:	91.3 ci 1.5 L
Power (gross):	34 hp 25.4 kW
Fuel system:	indirect injection
Pre-heating:	glow plugs
Rated RPM:	2800
Starter volts:	12

Dimensions
Wheelbase:	63 inches 160 cm
Length:	106.2 inches 269 cm
Width:	54.3 inches 137 cm
Height (ROPS):	87.8 inches 223 cm
Shipping weight:	2,402 lbs 1089 kg
Ground clearance:	15.1 inches 38 cm
Front tread:	43.4 inches 110 cm
Rear tread:	42.8 inches 108 cm
