Minneapolis-Moline ZTS
Type: Standard-tread Tractors
Contents:
Production | |
| Manufacturer: | Minneapolis-Moline |
| Type: | Standard-tread tractor |
| Factory: | Minneapolis, Minnesota, USA |
Variants | |
| row-crop | |
| standard front | |
| industrial |
Minneapolis-Moline ZTS Power | |
| Drawbar (claimed): | 16 hp 11.9 kW |
| PTO (claimed): | 25 hp 18.6 kW |
Mechanical | |
| Chassis: | 4x2 2WD |
| Steering: | manual |
| Brakes: | drum |
| Cab: | Open operator station. |
| Transmission: | 5-speed unsynchronized gear |
ZTS Serial Numbers | |
| 1937: | 610001 |
| 1938: | 610036 |
| 1939: | 610389 |
| 1940: | 610685 |
| 1941: | 611088 |
| 1942: | 611343 |
| 1943: | 611447 |
| 1944: | 611966 |
| 1945: | 612486 |
| 1946: | 612886 |
| 1947: | 613086 |
| Final: | 613490 |
Engine Detail | |
| Minneapolis-Moline RE | |
| gasoline | |
| 4-cylinder | |
| liquid-cooled | |
| Displacement: | 185.8 ci 3.0 L |
| Bore/Stroke: | 3.625x4.50 inches 92 x 114 mm |
| Compression: | 5.75:1 |
| Rated RPM: | 1500 |
| Firing order: | 1-3-4-2 |
Transmission | |
| Type: | unsynchronized gear |
| Gears: | 5 forward and 1 reverse |
| Clutch: | dry disc |
