Massey-Harris 444
Type: Row-crop Tractors
Contents:
Production | |
| Manufacturer: | Massey-Harris |
| Type: | Row-Crop tractor |
| Factory: | Racine, Wisconsin, USA |
| Total built: | 7,131 |
| Original price: | $3,650 (1958) |
Massey-Harris 444 Power | |
| Drawbar (claimed): | 35 hp 26.1 kW |
| PTO (claimed): | 48 hp 35.8 kW |
| Belt (claimed): | 43 hp 32.1 kW |
| Drawbar (tested): | 45.3 hp 33.8 kW |
| Belt (tested): | 49.24 hp 36.7 kW |
Mechanical | |
| Chassis: | 4x2 2WD |
| Steering: | manual |
| power optional | |
| Brakes: | differential mechanical shoe |
| Cab: | Open operator station. |
| Transmission: | 10-speed gear |
Power Take-off (PTO) | |
| Rear PTO: | independent |
| Rear RPM: | 540 |
Engine Detail | |
| Massey Harris | |
| diesel | |
| 4-cylinder | |
| liquid-cooled vertical I-head | |
| Displacement: | 277 ci 4.5 L |
| Bore/Stroke: | 4.00x5.50 inches 102 x 140 mm |
| Air cleaner: | oil bath |
| Compression: | 15.9:1 |
| Rated RPM: | 1500 |
| Starter volts: | 12 |
| Coolant capacity: | 22 qts 20.8 L |
Transmission | |
| Type: | gear |
| Gears: | 10 forward and 2 reverse |
| Five gears, plus reverse, in two ranges. | |
Dimensions | |
| Wheelbase: | 88.125 inches 223 cm |
| Operating weight: | 6,500 lbs 2948 kg |
| Ballasted weight: | 9,489 lbs 4304 kg |
