Massey Ferguson 3425

Production: 2005 - 2010

Production
Manufacturer:	Massey Ferguson
Type:	Orchard/Vineyard tractor

Variants
3425V:	narrow vineyard model
3425S:	standard
3425F:	fruit
3425GE:	ground effect low-profile model

Massey Ferguson 3425 Power
Engine:	64 hp 47.7 kW
PTO (claimed):	57 hp 42.5 kW

Mechanical
Chassis:	4x4 MFWD 4WD
Steering:	hydrostatic power
Brakes:	hydraulic wet disc
Cab:	Two-post mid-mount foldable ROPS. Cab optional.
Transmissions:	20-speed
30-speed

Hydraulics
Pressure:	2610 psi 180.0 bar
Valves:	2 to 3 rear
2 mid optional
Pump flow:	13.7 gpm 51.9 lpm
16.4 gpm 62.1 lpm (optional tandem pump)
Steering flow:	6.6 gpm 25.0 lpm

Tractor hitch
Rear Type:	1/2
Rear lift (at ends):	5,732 lbs 2600 kg
Rear lift (at 24"/610mm):	3,527 lbs 1599 kg

Power Take-off (PTO)
Rear RPM:	540/540E/1000

Electrical
Ground:	negative
Charging system:	alternator
Battery volts:	12

Engine Detail
Perkins 1103C-33T
turbocharged diesel
3-cylinder
liquid-cooled
Displacement:	201.4 ci 3.3 L
Emissions:	Tier II
Power:	64 hp 47.7 kW
Air cleaner:	dual dry element
Rated RPM:	2200
Torque:	46.8 lb-ft 63.5 Nm
Torque RPM:	2200
Starter:	electric
Starter volts:	12

Dimensions
Wheelbase:	78.74 inches 199 cm (S/F)
80.71 inches 205 cm (V/GE)
Length:	145.64 inches 369 cm
Width:	43.4 inches 110 cm (V)
46.9 inches 119 cm (S)
50.2 inches 127 cm (GE)
56.4 inches 143 cm (F)
