Massey Ferguson 2800
Type: Row-crop Tractors
Contents:
Production | |
| Manufacturer: | Massey Ferguson |
| Type: | Row-Crop tractor |
| Original price: | $36,000 (1977 ) |
Massey Ferguson 2800 Power | |
| PTO (claimed): | 190 hp 141.7 kW |
Mechanical | |
| Chassis: | 4x2 2WD |
| Differential lock: | hydraulic rear |
| Steering: | hydrostatic power |
| Brakes: | hydraulic disc |
| Cab: | Cab standard. |
| Transmissions: | 24-speed 3-speed power shift |
| 8-speed mechanical shuttle | |
Hydraulics | |
| Type: | open center |
| Valves: | 2 or 3 |
| Pump flow: | 16.5 gpm 62.5 lpm |
| Steering flow: | 5.5 gpm 20.8 lpm |
Tractor hitch | |
| Rear Type: | III/II (optional) |
| Control: | position and draft control |
| Drawbar: | swinging drawbar |
| heavy-duty wide-swinging (Western) | |
Power Take-off (PTO) | |
| Rear PTO: | independent |
| Clutch: | hydraulic |
| Rear RPM: | 1000 (1.75) |
| 1000 (1.375 opt.) | |
| Engine RPM: | 1000@2100 |
Electrical | |
| Ground: | negative |
| Charging system: | alternator |
| Charging amps: | 58 |
| Charging volts: | 12 |
| Battery volts: | 12 |
Engine Detail | |
| Perkins ATV8.640 | |
| turbocharged diesel | |
| 8-cylinder | |
| liquid-cooled | |
| Displacement: | 640 ci 10.5 L |
| Bore/Stroke: | 4.63x4.75 inches 118 x 121 mm |
| Fuel system: | CAV rotary pump |
| Air cleaner: | dual stage dry |
| Compression: | 16:1 |
| Rated RPM: | 2500 |
| Starter: | 12 |
| Starter volts: | 12 |
| Oil capacity: | 24 qts 22.7 L |
| Coolant capacity: | 55 qts 52.1 L |
Dimensions | |
| Wheelbase: | 110 inches 279 cm |
| Length: | 190 inches 482 cm |
| Weight: | 13000 lbs 5896 kg |
| Clearance (front axle): | 25.4 inches 64 cm |
| Clearance (rear axle): | 15.7 inches 39 cm |
| Rear axle: | 3.75 by 91.6 inches 95 by 2326 mm |
| Rear axle: | 3.75 by 125.7 inches 95 by 3192 mm |
| Rear axle: | 3.75 by 156.9 inches 95 by 3985 mm |
| Front tread: | 56 to 80 inches 142 to 203 cm (row-crop) |
| Front tread: | 56 inches 142 cm (Western) |
| Rear tread: | 71 to 92 inches 180 to 233 cm (standard) |
| Rear tread: | 71 to 126 inches 180 to 320 cm (long) |
| Rear tread: | 71 to 161 inches 180 to 408 cm (extra long) |
