Massey Ferguson 1250

Production: 1992 - 2002

Production
Distributor:	Massey Ferguson
Manufacturer:	Iseki
Type:	Compact Utility tractor
Original price:	$16,000 (1999 )

Massey Ferguson 1250 Power
Engine (gross):	34 hp 25.4 kW
Engine (net):	32 hp 23.9 kW
PTO (claimed):	27.3 hp 20.4 kW

Mechanical
Chassis:	4x2 2WD
4x4 MFWD 4WD
Steering:	power assist
Brakes:	wet disc
Cab:	Two-post foldable ROPS.
Transmission:	16-speed synchro shuttle

Capacity
Fuel:	7.9 gal 29.9 L
Hydraulic system:	6.6 gal 25.0 L

Hydraulics
Type:	open center
Capacity:	6.6 gal 25.0 L
Pump flow:	6.3 gpm 23.8 lpm
Total flow:	9.6 gpm 36.3 lpm

Tractor hitch
Rear Type:	I
Control:	position control
Rear lift (at ends):	2866 lbs 1300 kg

Power Take-off (PTO)
Rear PTO:	independent
Clutch:	electro-hydraulic
Rear RPM:	540 (1.375)
Engine RPM:	540@2389
Mid PTO:	independent (optional)
Clutch:	electro-hydraulic
Mid RPM:	1960
Engine RPM:	1960@2600

1250 Serial Numbers
1992:	A00001
1993:	B00001
1994:	C00001
1995:	D00001
1996:	E00001
1997:	FF00001
1998:	GF00001
1999:	HF00001
2000:	JF00001
2001:	KF00001

Electrical
Ground:	negative
Battery volts:	12

Engine Detail
Iseki TK532
diesel
3-cylinder
liquid-cooled
Displacement:	91.4 ci 1.5 L
Power (gross):	34 hp 25.4 kW
Fuel system:	indirect injection
Air cleaner:	dry
Pre-heating:	glow plugs
Compression:	21.8:1
Rated RPM:	2600
Torque:	74 lb-ft 100.3 Nm
Torque RPM:	1600
Starter volts:	12
Coolant capacity:	6.92 qts 6.5 L

Transmission
Type:	synchro shuttle
Gears:	16 forward and reverse
Clutch:	225mm dry disc
Four gears in four ranges with shuttle.

Dimensions
Wheelbase:	67.9 inches 172 cm
Length:	121.9 inches 309 cm
Width:	55.3 inches 140 cm (min)
Height (ROPS):	85.4 inches 216 cm
68.9 inches 175 cm (folded)
Weight:	2690 lbs 1220 kg (2WD)
2746 lbs 1245 kg (4WD)
Ground clearance:	12.2 inches 30 cm
Front tread:	39 to 50.9 inches 99 to 129 cm (2WD)
Front tread:	42.2 inches 107 cm (4WD)
Rear tread:	43.3 to 55.9 inches 109 to 141 cm
