Lanz 500
Contents:
Production | |
| Manufacturer: | Lanz (a part of John Deere) |
| Factory: | Mannheim, Baden-Württemberg, Germany |
Lanz 500 Power | |
| Engine: | 42 hp 31.3 kW |
Mechanical | |
| Chassis: | 4x2 2WD |
| Steering: | manual |
| Brakes: | disc |
| Cab: | Open operator station. |
| Transmission: | 10-speed constant mesh |
Tractor hitch | |
| Rear Type: | II/I |
Power Take-off (PTO) | |
| Rear RPM: | 540/1000 |
| Mid PTO: | standard |
| Mid RPM: | 1000 |
Engine Detail | |
| John Deere | |
| diesel | |
| 4-cylinder | |
| liquid-cooled | |
| The Deere-Lanz 500 used the same diesel engine as the Deere 1010 | |
| Displacement: | 144.5 ci 2.4 L |
| Bore/Stroke: | 3.625x3.50 inches 92 x 89 mm |
| Power: | 42 hp 31.3 kW |
| Rated RPM: | 2500 |
Transmission | |
| Type: | constant mesh |
| Gears: | 10 forward and 3 reverse |
Dimensions | |
| Shiping weight: | 4550 lbs 2063 kg |
