Landini Evolution 6865

Production
Manufacturer:	Landini

Landini Evolution 6865 Power
Engine:	67.3 hp 50.2 kW
PTO (claimed):	62.4 hp 46.5 kW

Mechanical
Chassis:	4x2 2WD
4x4 MFWD 4WD optional
Steering:	hydrostatic power
Brakes:	wet disc
Cab:	4-post frame
Transmissions:	12-speed
24-speed

Capacity
Fuel:	23 gal 87.1 L
Hydraulic system:	12.1 gal 45.8 L

Hydraulics
Capacity:	12.1 gal 45.8 L
Pressure:	2600 psi 179.3 bar
Valves:	2
Pump flow:	13.8 gpm 52.2 lpm
Total flow:	20.2 gpm 76.5 lpm

Tractor hitch
Rear Type:	II
Rear lift:	5,720 lbs 2594 kg
8,140 lbs 3692 kg optional

Power Take-off (PTO)
Rear RPM:	540

Engine Detail
Perkins 1104C-44
diesel
4-cylinder
Displacement:	268 ci 4.4 L
Bore/Stroke:	4.00x5.00 inches 102 x 127 mm
Power:	67.3 hp 50.2 kW
Rated RPM:	2200
Torque:	201 lb-ft 272.6 Nm
Torque RPM:	1400

Dimensions
Wheelbase:	88.5 inches 224 cm
Length:	134.8 inches 342 cm
Width:	72 inches 182 cm
Height:	100 inches 254 cm
Weight:	6,090 lbs 2762 kg
Ground clearance:	15.4 inches 39 cm
