Wheel Horse 269-H

Production: 1996 - 1998
Type: Garden Tractors

Contents:

Production

ManufacturerWheel Horse (a part of Toro)
TypeGarden tractor

Mechanical

Chassis4x2 2WD
Steeringmanual
CabOpen operator station.

269-H Serial Numbers

Location:Serial number decal on the rear fender deck, below the seat.
19966900001
19977900001
19988900001

Electrical

Groundnegative
Battery volts12

Engine Detail

Kohler CV19S
gasoline
2-cylinder
air-cooled vertical-shaft V-Twin
Displacement624 cc 38.1 ci
Bore/Stroke3.03x2.64 inches 77 x 67 mm
Power (gross)19 hp 14.2 kW
Starterelectric
Starter volts12

Transmission

TransmissionTuff Torq K-61A
Typebelt-driven hydrostatic
Gearsinfinite forward and reverse
Oil capacity3.5 qts 3.3 L
Oil typeSAE 10W-30

Dimensions

Wheelbase49.5 inches 125 cm
Length69 inches 175 cm
Width35.5 inches 90 cm
Weight560 lbs 254 kg
