Toro 935
Type: Lawn Tractors
Contents:
Production | |
| Manufacturer: | Toro |
| Type: | Lawn tractor |
Variants | |
| 935: | recoil start |
| 935E: | electric start |
Mechanical | |
| Steering: | manual |
| Transmission: | 3-speed gear |
Capacity | |
| Fuel: | 1 gal 3.8 L |
Power Take-off (PTO) | |
| Mid PTO: | independent |
| Clutch: | manual |
935 Serial Numbers | |
| 1969: 9000001 |
Electrical | |
| Ground: | negative |
Engine Detail | |
| Tecumseh V70 | |
| gasoline | |
| 1-cylinder | |
| air-cooled vertical-shaft | |
| Displacement: | 245 cc 15 ci |
| Bore/Stroke: | 2.75x2.531 inches 70 x 64 mm |
| Power (gross): | 7 hp 5.2 kW |
| Air cleaner: | dry |
| Starter: | recoil |
| electric*Optional. Electric start on models 55050, recoil on 55002. | |
| Starter volts: | 12 |
Transmission | |
| Transmission: | Peerless 615 |
| Type: | belt-driven gear |
| Gears: | 3 forward and 1 reverse |
| Clutch: | mechanical idler pulley |
Dimensions | |
| Wheelbase: | 42 inches 106 cm |
| Length: | 57 inches 144 cm |
| Width: | 32 inches 81 cm |
| Height: | 35 inches 88 cm |
| Weight: | 330 lbs 149 kg *With mower deck |
| Front tread: | 25 inches 63 cm |
| Rear tread: | 23.75 inches 60 cm |
