Toro 800
Type: Lawn Tractors
Contents:
Production | |
| Manufacturer: | Toro |
| Type: | Lawn tractor |
Mechanical | |
| Steering: | manual |
| Transmission: | 3-speed gear |
Capacity | |
| Fuel: | 0.9 gal 3.4 L |
Power Take-off (PTO) | |
| Mid PTO: | independent |
| Clutch: | manual |
800 Serial Numbers | |
| 1970: 0000001 (55003/55051) 1971: 1000001 (55055) |
Electrical | |
| Ground: | negative |
Engine Detail | |
| Briggs & Stratton 190707 | |
| gasoline | |
| 1-cylinder | |
| air-cooled vertical-shaft | |
| Displacement: | 318 cc 19.44 ci |
| Bore/Stroke: | 3.00x2.75 inches 76 x 70 mm |
| Power (gross): | 8 hp 6.0 kW |
| Starter: | recoil |
| electric*Optional. Electric start on models 55051 and 55055, recoil on 55003. | |
| Starter volts: | 12 |
Transmission | |
| Transmission: | Peerless 615 |
| Type: | belt-driven gear |
| Gears: | 3 forward and 1 reverse |
| Clutch: | mechanical idler pulley |
Dimensions | |
| Wheelbase: | 42 inches 106 cm |
| Length: | 56.5 inches 143 cm |
| Width: | 30 inches 76 cm |
| Height: | 35 inches 88 cm |
| Weight: | 370 lbs 167 kg *With mower deck |
| Front tread: | 25 inches 63 cm |
| Rear tread: | 22.75 inches 57 cm |
