Sabre 2048HV

Production: 1998 - 1999
Type: Garden Tractors

Contents:

Production

ManufacturerSabre (a part of John Deere)
TypeGarden tractor
FactoryHoricon, Wisconsin, USA

Mechanical

Chassis4x2 2WD
Steeringmanual sector-and-pinion
Brakesdisc
CabOpen operator station.

Tractor hitch

Typesleeve hitch OptOptional

Power Take-off (PTO)

Front PTOindependent
Clutchelectric

2048HV Serial Numbers

1998010001
1999020001

2048HV Serial Location

Serial number decal on the rear of tractor above the drawbar.

Electrical

Groundnegative
Charging systemflywheel alternator
Charging amps16
Battery CCA340
Battery volts12
Battery GroupBCI U1

Engine Detail

Briggs & Stratton 351777
gasoline
2-cylinder
air-cooled V-twin OHV
Displacement568 cc 34.7 ci
Power (gross)20 hp 14.9 kW
Air cleanerdry with foam precleaner
Idle RPM1550-3550
Starter volts12

Transmission

TransmissionKanzaki Tuff Torq K65
Typehydrostatic
Gearsinfinite forward and reverse
Oil capacity3.4 qts 3.2 L

Dimensions

Wheelbase48.5 inches 123 cm
Length72 inches 182 cm
Width38.2 inches 97 cm
Height44.9 inches 114 cm
