Production | |
Manufacturer | John Deere |
Type | Lawn tractor |
Original price | $3,999 (2016 ) |
Mechanical | |
Chassis | 4x2 2WD |
Steering | power |
Brakes | wet disc |
Cab | Open operator station with 15-inch seat. |
Power Take-off (PTO) | |
Mid PTO | independent |
Clutch | electric |
X370 Serial Numbers | |
2016 | 10001 |
2017 | 30001 |
2018 | 50001 |
2019 | 70001 |
2020 | 90001 |
2021 | 110001 |
X370 Serial Location | |
Serial number tag on the right side of the tractor frame, above the front axle. |
Electrical | |
Ground | negative |
Charging system | flywheel alternator |
Charging amps | 15 |
Battery CCA | 340 |
Battery volts | 12 |
Engine Detail | |
Kawasaki FS600V | |
gasoline | |
2-cylinder | |
air-cooled vertical-shaft V-Twin | |
Displacement | 603 cc 36.8 ci |
Bore/Stroke | 2.87x2.84 inches 73 x 72 mm |
Power (gross) | 18.5 hp 13.8 kW |
Fuel system | carburetor |
Air cleaner | dry with foam precleaner |
Rated RPM | 3600 |
Starter | electric |
Starter volts | 12 |
Sparkplug gap | 0.030 inches 0.762 mm |
Transmission | |
Transmission | Tuff Torq K57 |
Type | belt-driven hydrostatic |
Gears | infinite forward and reverse |
Oil capacity | 2.4 qts 2.3 L |
Oil type | JD Low-Vis Hy-Gard |
Dimensions | |
Wheelbase | 49.4 inches 125 cm |
Length | 72 inches 182 cm |
Width | 38 inches 96 cm |
Height | 47 inches 119 cm |
Weight | 491 lbs 222 kg |
Front axle | Cast-iron |
