John Deere S240 Sport
Type: Lawn Tractors
Contents:
Production | |
| Manufacturer | John Deere |
| Type | Lawn tractor |
| Factory | Greenville, Tennessee, USA |
| Original price | $2,500 (2015 ) |
Mechanical | |
| Chassis | 4x2 2WD |
| Steering | manual |
| Cab | Open operator station. |
Power Take-off (PTO) | |
| Mid PTO | independent |
| Clutch | electric |
S240 Serial Numbers | |
| Location: | Serial number plate on the rear of the S240. |
| 2015 | 100001 |
| 2016 | 700001 |
| 2017 | 810001 |
| 2018 | 825001 |
| 2019 | 850001 |
| 2020 | 870001 |
| 2021 | 880001 |
Electrical | |
| Ground | negative |
| Charging system | flywheel alternator |
| Charging amps | 15 |
| Battery volts | 12 |
| Battery Group | U1 |
Engine Detail | |
| Kawasaki FS600V | |
| gasoline | |
| 2-cylinder | |
| air-cooled vertical-shaft V-Twin | |
| Displacement | 603 cc 36.8 ci |
| Bore/Stroke | 2.87x2.84 inches 73 x 72 mm |
| Power (gross) | 18.5 hp 13.8 kW |
| Fuel system | carburetor |
| Air cleaner | foam and paper cartridge |
| Compression | 8.1:1 |
| Starter | electric |
| Starter volts | 12 |
| Sparkplug gap | 0.030 inches 0.762 mm |
Transmission | |
| Transmission | Tuff Torq K46DP |
| Type | belt-driven hydrostatic |
| Gears | infinite forward and reverse |
| Oil change | sealed unit, owner service is not recommended |
Dimensions | |
| Wheelbase | 48.9 inches 124 cm |
| Length | 75.1 inches 190 cm |
| Width | 44.6 inches 113 cm |
| Weight | 458 lbs*Weight with mower deck 207 kg |
| Front axle | Cast-iron |
