Bolens 2000H 5020H

Production: 1986 - 1988

Production
Manufacturer:	Bolens
Type:	Garden tractor

Mechanical
Chassis:	4x2 2WD
Steering:	manual
Cab:	Open operator station. Soft-side weather cab optional.
Transmission:	hydrostatic

Capacity
Fuel:	3.5 gal 13.2 L

Tractor hitch
Rear Type:	0*Optional
Type:	sleeve hitch*Optional

Power Take-off (PTO)
Front PTO:	independent
Clutch:	electric

Electrical
Ground:	negative

Engine Detail
Kohler M20QS
gasoline
2-cylinder
air-cooled horizontal-shaft
Displacement:	770 cc 46.98 ci
Bore/Stroke:	3.125x3.0625 inches 79 x 78 mm
Power (gross):	20 hp 14.9 kW
Compression:	6.6:1
Starter:	electric
Starter volts:	12
Oil capacity:	1.5 qts 1.4 L
Sparkplug:	Champion RV15YC
Sparkplug gap:	0.025 inches 0.635 mm

Transmission
Transmission:	Eaton 11
Type:	shaft-driven hydrostatic
Gears:	infinite (2-range) forward and reverse

Dimensions
Wheelbase:	47 inches 119 cm
Length:	70.5 inches 179 cm
Width:	40.5 inches 102 cm
Height:	45 inches 114 cm
Shipping:	888 lbs 402 kg
