Kubota T240

Production: 2000 - 2002

Production
Manufacturer:	Kubota
Type:	Compact Utility tractor

Variants
T240:	gear
T240F:	4WD

Kubota T240 Power
Engine:	23.7 hp 17.7 kW

Mechanical
Chassis:	4x4 MFWD 4WD
Cab:	Two-post folding ROPS.
Transmissions:	12-speed gear
hydrostatic

Tractor hitch
Rear Type:	JIS-1

Power Take-off (PTO)
Rear RPM:	540 (1.375)
Engine RPM:	525@2600 760@2600 1182@2600 -518@2600

Electrical
Ground:	negative
Charging system:	alternator
Battery volts:	12

Engine Detail
Kubota D1463
disel
3-cylinder
liquid-cooled
Displacement:	89.3 ci 1.5 L
Bore/Stroke:	3.23x3.64 inches 82 x 92 mm
Power:	23.7 hp 17.7 kW
Rated RPM:	2600
Starter:	electric
Starter volts:	12

Dimensions
Wheelbase:	57.1 inches 145 cm
Length:	112.4 inches 285 cm
Width:	46.7 inches 118 cm
Height:	74.6 inches 189 cm
Gear Weight:	1984 lbs 899 kg
Hydro Weight:	2072 lbs 939 kg
Ground clearance:	12.6 inches 32 cm
Front tread:	37.4 inches 94 cm
Rear tread:	37.4/42.1 inches 94/106 cm
