John Deere 3155
Type: Utility Tractors
Contents:
Production | |
| Manufacturer: | John Deere |
| Type: | Utility tractor |
| Factory: | Mannheim, Baden-Württemberg, Germany |
| Original price: | $43,000 (1992 ) |
John Deere 3155 Power | |
| PTO (claimed): | 95 hp 70.8 kW |
| Drawbar (tested): | 81.92 hp 61.1 kW |
| PTO (tested): | 96.06 hp 71.6 kW |
Mechanical | |
| Chassis: | 4x4 MFWD 4WD |
| Steering: | power |
| Brakes: | hydraulic wet disc |
| Cab: | Two-post ROPS. Sound-Gard Cab optional. |
| Transmissions: | 8-speed partially synchronized |
| 16-speed partial power shift | |
Hydraulics | |
| Type: | closed center |
| Valves: | 2 or 3 |
| Pump flow: | 22 gpm 83.3 lpm |
Tractor hitch | |
| Rear Type: | II |
| Rear lift: | 6308 lbs 2861 kg |
Power Take-off (PTO) | |
| Rear PTO: | independent |
| Rear RPM: | 540/1000 |
3155 Serial Numbers | |
| Location: | Serial number plate on the right side of the tractor frame. |
| 1987: | 618645 |
| 1988: | 624591 |
| 1989: | 653652 |
| 1990: | 685545 |
| 1991: | 717916 |
Electrical | |
| Ground: | negative |
| Charging system: | alternator |
| Charging amps: | 85 |
| Batteries: | 2 |
| Battery CCA: | 610 |
| Battery volts: | 12 |
Engine Detail | |
| John Deere | |
| diesel | |
| 6-cylinder | |
| liquid-cooled | |
| Displacement: | 359 ci 5.9 L |
| Bore/Stroke: | 4.19x4.33 inches 106 x 110 mm |
| Air cleaner: | dual paper elements |
| Compression: | 17.8:1 |
| Rated RPM: | 2400 |
| Starter volts: | 12 |
| Oil capacity: | 12.2 qts 11.5 L |
| Coolant capacity: | 18 qts 17.0 L |
Dimensions | |
| Wheelbase: | 101.7 inches 258 cm |
