Deere 2155
Type: Utility Tractors
Contents:
Production | |
| Manufacturer: | John Deere |
| Type: | Utility tractor |
| Factory: | Mannheim, Baden-Württemberg, Germany |
| Original price: | $18,000 (1992 ) |
John Deere 2155 Power | |
| Engine: | 55 hp 41.0 kW |
| CST PTO (claimed): | 45 hp 33.6 kW |
| TSS PTO (claimed): | 46 hp 34.3 kW |
| Drawbar (tested): | 37.4 hp 27.9 kW |
| PTO (tested): | 45.6 hp 34.0 kW |
Mechanical | |
| Chassis: | 4x2 2WD |
| 4x4 MFWD 4WD | |
| Steering: | power |
| Brakes: | differential hydraulic wet disc |
| Cab: | Roll-Gard ROPS. |
| Transmissions: | 8-speed non-synchronized |
| 8-speed partially synchronized | |
| 16-speed partial power shift | |
| 8-speed power shuttle | |
Hydraulics | |
| Type: | closed center |
| Pressure: | 2250 psi 155.1 bar |
| Valves: | 0 to 3 |
| Total flow: | 13 gpm 49.2 lpm |
Tractor hitch | |
| Rear Type: | II/I |
| Rear lift: | 2,495 lbs 1131 kg |
Power Take-off (PTO) | |
| Rear PTO: | live*Two-stage clutch |
| independent*Optional | |
| Rear RPM: | 540 |
2155 Serial Numbers | |
| Location: | Serial number plate on the right side of the tractor frame, above the front axle. |
| 1987: | 600000 |
| 1988: | 624800 |
| 1989: | 652073 |
| 1990: | 686146 |
| 1991: | 717916 |
| 1992: | 746510 |
Electrical | |
| Ground: | negative |
| Charging system: | alternator |
| Charging amps: | 55 |
| Batteries: | 2 |
| Battery CCA: | 400 |
| Battery volts: | 12 |
Engine Detail | |
| John Deere | |
| diesel | |
| 3-cylinder | |
| liquid-cooled | |
| Displacement: | 179 ci 2.9 L |
| Bore/Stroke: | 4.19x4.33 inches 106 x 110 mm |
| Power: | 55 hp 41.0 kW |
| Compression: | 17.8:1 |
| Rated RPM: | 2300 (CST) |
| 2500 (TSS) | |
| Starter volts: | 12 |
| Oil capacity: | 6.3 qts 6.0 L |
| Coolant capacity: | 10.6 qts 10.0 L |
Dimensions | |
| Wheelbase: | 80.7 inches 204 cm |
| Shiping weight: | 4983 lbs 2260 kg (2WD ROPS) |
| 5755 lbs 2610 kg (4WD ROPS) | |
