John Deere 2305
Contents:
Production | |
| Manufacturer: | John Deere |
| Type: | Sub-Compact Utility tractor |
| Factory: | Augusta, Georgia, USA |
| Original price: | $11,069 (2011 ) |
John Deere 2305 Power | |
| Engine (gross): | 24.1 hp 18.0 kW |
| PTO (claimed): | 18 hp 13.4 kW |
Mechanical | |
| Chassis: | 4x4 MFWD 4WD |
| Final drives: | spur gear |
| Steering: | power |
| Brakes: | wet disc |
| Cab: | Two-post fixed ROPS. |
| Transmission: | hydrostatic |
Capacity | |
| Fuel: | 5.5 gal 20.8 L |
| Hydraulic system: | 3.4 gal 12.9 L |
| Front axle: | 2.6 qts 2.5 L |
Hydraulics | |
| Type: | open center |
| Capacity: | 3.4 gal 12.9 L |
| Pressure: | 1987 psi 137.0 bar |
| Valves: | 2 |
| Pump flow: | 2.9 gpm 11.0 lpm |
| Total flow: | 5.2 gpm 19.7 lpm |
| Steering flow: | 2.3 gpm 8.7 lpm |
Tractor hitch | |
| Rear Type: | I (limited) |
| Rear lift (at ends): | 1433 lbs 650 kg |
| Rear lift (at 24"/610mm): | 681 lbs 308 kg |
Power Take-off (PTO) | |
| Rear PTO: | independent |
| Rear RPM: | 540 |
| Mid PTO: | independent |
| Mid RPM: | 2100 |
2305 Serial Numbers | |
| Location: | Serial number plate on the right side of the John Deere 2305 tractor frame, above the front wheel. |
| 2005: | 100001 |
| 2006: | 200001 |
| 2007: | 320001 |
| 2008: | 420001 |
| 2009: | 520001 |
| 2010: | 620001 |
Electrical | |
| Ground: | negative |
| Charging system: | alternator |
| Charging amps: | 20 |
| Battery CCA: | 500 |
| Battery volts: | 12 |
Engine Detail | |
| Yanmar 3TNV76 | |
| diesel | |
| 3-cylinder | |
| liquid-cooled | |
| Displacement: | 68 ci 1.1 L |
| Bore/Stroke: | 2.99x3.23 inches 76 x 82 mm |
| Rated Power (EC 97/98): | 24.1 hp 18.0 kW |
| Air cleaner: | dual dry element |
| Compression: | 23.4:1 |
| Rated RPM: | 3000 |
| Operating RPM: | 1170-3170 |
| Torque: | 41.7 lb-ft 56.5 Nm |
| Torque RPM: | 3000 |
| Starter volts: | 12 |
| Starter power: | 1.6 hp 1.2 kW |
| Coolant capacity: | 3.4 qts 3.2 L |
Transmission | |
| Type: | hydrostatic |
| Gears: | infinite (2-range) forward and reverse |
| Oil capacity: | 13.6 qts 12.9 L |
| Hydrostatic transmission operated with two foot pedals and range-shift lever. Tractor must be stopped to shift ranges. Optional cruise control is engaged by dashboard button. | |
Dimensions | |
| Wheelbase: | 57.1 inches 145 cm |
| Length: | 102.6 inches 260 cm |
| Width: | 44.9 inches 114 cm |
| Height (hood): | 42 inches 106 cm |
| Height (ROPS): | 77.5 inches 196 cm |
| Clearance (front axle): | 7.7 inches 19 cm |
| Front tread: | 39.6 inches 100 cm |
| Rear tread: | 33.6 inches 85 cm |
