J.I. Case CF 350

Production: 1962 - 1966

Production
Manufacturer:	J.I. Case
Type:	Utility tractor
Factory:	Vierzon, France

J.I. Case CF 350 Power
Engine:	35 hp 26.1 kW

Mechanical
Chassis:	4x2 2WD
Final drives:	planetary
Differential lock:	mechanical rear
Steering:	manual
Brakes:	mechanical drum
Cab:	Open operator station.
Transmission:	8-speed gear

Capacity
Fuel:	13.2 gal 50.0 L
Hydraulic system:	2.25 gal 8.5 L

Hydraulics
Capacity:	2.25 gal 8.5 L

Tractor hitch
Rear Type:	II/I

Power Take-off (PTO)
Rear PTO:	independent
Rear RPM:	540/1000
Mid PTO:	independent
Mid RPM:	1000

Engine Detail
Indenor XDP85
diesel
4-cylinder
liquid-cooled
Displacement:	110.8 ci 1.8 L
Bore/Stroke:	3.35x3.15 inches 85 x 80 mm
Power:	35 hp 26.1 kW
Fuel system:	indirect injection
Air cleaner:	oil bath
Compression:	21:1
Rated RPM:	2500
Starter:	electric
Starter volts:	12
Oil capacity:	4.2 qts 4.0 L
Coolant capacity:	10.8 qts 10.2 L

Transmission
Type:	gear
Gears:	8 forward and 4 reverse
Four gears in two ranges, plus reverse range.

Dimensions
Wheelbase:	72.8 inches 184 cm
Length:	120.9 inches 307 cm
Width:	64.6 inches 164 cm
Height:	63.8 inches 162 cm
Weight:	3748 lbs 1700 kg
Ground clearance:	19.7 inches 50 cm
Front tread:	44.1 to 66.9 inches 112 to 169 cm
Rear tread:	40.2 to 67.7 inches 102 to 171 cm
