J.I. Case 910-B

Production: 1957 - 1959
Type: Standard-tread Tractors

Contents:

Production

Manufacturer:J.I. Case
Type:Standard-tread tractor
Factory:Racine, Wisconsin, USA
Total built:1,000
Original price:$5,500 (1960)

Variants

diesel
LP-gas

J.I. Case 910-B Power

Plows:5-6
Drawbar (tested):62.14 hp 46.3 kW
PTO (tested):71.05 hp 53.0 kW

Mechanical

Chassis:4x2 2WD
Steering:power assist
Brakes:disc
Cab:Open operator station.
Transmission:6-speed gear

Power Take-off (PTO)

Rear PTO:independent
Rear RPM:540

Engine Detail

J.I. Case
LP gas
6-cylinder
liquid-cooled
Displacement:377 ci 6.2 L
Bore/Stroke:4.00x5.00 inches 102 x 127 mm
Compression:7.5:1
Rated RPM:1350
Starter volts:12
Oil capacity:12 qts 11.4 L

Transmission

Type:gear
Gears:6 forward and 1 reverse
Clutch:oil cushion

Dimensions

Wheelbase:84 inches 213 cm
Length:141 inches 358 cm
Operating weight:8,550 lbs 3878 kg
Ballasted weight:14,755 lbs 6692 kg
Front tread:54.75 inches 139 cm
Rear tread:67.5 inches 171 cm
