Iseki TL4100

Production: 1980 - 1985

Production
Manufacturer:	Iseki
Type:	Utility tractor

Iseki TL4100 Power
Engine:	40.4 hp 30.1 kW

Mechanical
Chassis:	4x2 2WD
4x4 MFWD 4WD
Steering:	power
Cab:	Four-post ROPS with canopy. Open station available.
Transmission:	18-speed

Tractor hitch
Rear Type:	JIS1
Control:	position and draft control

Power Take-off (PTO)
Rear RPM:	540 (1.375)
Engine RPM:	602@2600 734@2600 959@2600 1566@2600

Electrical
Ground:	negative
Charging system:	alternator
Battery volts:	12

Engine Detail
Isuzu 4FC1
diesel
4-cylinder
liquid-cooled
Displacement:	121.7 ci 2.0 L
Bore/Stroke:	3.31x3.54 inches 84 x 90 mm
Power:	40.4 hp 30.1 kW
Rated RPM:	2600
Starter:	electric
Starter volts:	12

Transmission
Gears:	18 forward and 6 reverse

Dimensions
Wheelbase:	76.4 inches 194 cm
Length:	134.5 inches 341 cm
Width:	61.4 inches 155 cm
Height (ROPS):	86.6 inches 219 cm
Height (exhaust):	79.9 inches 202 cm
Ground clearance:	15.4 inches 39 cm
2WD 115 to 154 cm 2WD} 48 inches 121 cm {4WD} Front tread:	45.3 to 61 inches
Rear tread:	48 to 63.8 inches 121 to 162 cm
