Iseki TL3700

Production: 1980 - 1985

Production
Manufacturer:	Iseki
Type:	Utility tractor

Iseki TL3700 Power
Engine:	36 hp 26.8 kW

Mechanical
Chassis:	4x2 2WD
4x4 MFWD 4WD
Steering:	power
Cab:	Four-post ROPS with canopy. Open station available.
Transmission:	18-speed

Tractor hitch
Rear Type:	JIS1
Control:	position and draft control

Power Take-off (PTO)
Rear RPM:	540 (1.375)
Engine RPM:	2600@590 2600@722 2600@945 2600@1540

Electrical
Ground:	negative
Charging system:	alternator
Battery volts:	12

Engine Detail
Isuzu 4FB1
diesel
4-cylinder
liquid-cooled
Displacement:	110.9 ci 1.8 L
Bore/Stroke:	3.31x3.23 inches 84 x 82 mm
Power:	36 hp 26.8 kW
Rated RPM:	2600
Starter:	electric
Starter volts:	12

Transmission
Gears:	18 forward and 6 reverse

Dimensions
Wheelbase:	70.9 inches 180 cm
Length:	126.4 inches 321 cm
Width:	60.2 inches 152 cm
Height (ROPS):	84.1 inches 213 cm
Height (exhaust):	78.7 inches 199 cm
Ground clearance:	14.2 inches 36 cm
2WD Front tread:	45.3 to 61 inches 115 to 154 cm
4WD Front tread:	47.6 inches 120 cm
Rear tread:	44.9 to 59.1 inches 114 to 150 cm
