Iseki TL4200

Production: 1980 - 1985

Production
Manufacturer:	Iseki
Type:	Compact Utility tractor

Iseki TL4200 Power
Engine:	41.4 hp 30.9 kW

Mechanical
Chassis:	4x2 2WD
4x4 MFWD 4WD
Cab:	Open operator station. Four-post ROPS available.
Transmission:	18-speed

Tractor hitch
Rear Type:	JIS1

Power Take-off (PTO)
Rear RPM:	540 (1.375)
Engine RPM:	593@2600 722@2600 945@2600 1540@2600

Electrical
Ground:	negative
Battery volts:	12

Engine Detail
Isuzu 4FA1
diesel
4-cylinder
liquid-cooled
Displacement:	90.7 ci 1.5 L
Power:	41.4 hp 30.9 kW
Rated RPM:	2600
Starter:	electric
Starter volts:	12

Transmission
Gears:	18 forward and 6 reverse

Dimensions
Wheelbase:	70.9 inches 180 cm
Length:	126.2 inches 320 cm
Width:	60 inches 152 cm
Height (exhaust):	76 inches 193 cm
2WD Weight:	2976 lbs 1349 kg
4WD Weight:	3241 lbs 1470 kg
Ground clearance:	14.2 inches 36 cm
2WD 115 to 154 cm 2WD} 47.6 inches 120 cm {4WD} Front tread:	45.3 to 61 inches
Rear tread:	44.9 to 59.1 inches 114 to 150 cm
