Iseki TJ65

Production: 2004 - 2009

Production
Manufacturer:	Iseki
Type:	Utility tractor

Variants
wheel tractor
TJ65C:	half-track

Iseki TJ65 Power
Engine:	64.1 hp 47.8 kW

Mechanical
Chassis:	4x4 MFWD 4WD
Differential lock:	mechanical rear
Steering:	power
Brakes:	wet discs
Cab:	Cab with air-conditioning.
Transmission:	24-speed 8-speed power shift

Tractor hitch
Rear Type:	JIS1
JIS2

Power Take-off (PTO)
Rear PTO:	independent
Rear RPM:	540 (1.375)
Engine RPM:	566@2600 733@2600 1062@2600

Electrical
Ground:	negative
Battery volts:	12
Battery AH:	72

Engine Detail
Iseki E4DE
diesel
4-cylinder
liquid-cooled
Displacement:	180.3 ci 3.0 L
Bore/Stroke:	3.82x3.94 inches 97 x 100 mm
Power:	64.1 hp 47.8 kW
Rated RPM:	2600
Starter:	electric
Starter volts:	12

Transmission
Type:	8-speed power shift
Gears:	24 forward and reverse
Eight push-button power shift gears in three ranges with power shuttle. Automated AT shift mode.

Dimensions
Wheelbase:	84.7 inches 215 cm
Length:	149.4 inches 379 cm
Width:	65.8 inches 167 cm
Height:	98 inches 248 cm
Weight:	5600 lbs 2540 kg
Ground clearance:	16.9 inches 42 cm
Front tread:	47.8 to 62.2 inches 121 to 157 cm
Rear tread:	48 to 63.4 inches 121 to 161 cm
