International Harvester 733
Type: Utility Tractors
Contents:
Production | |
| Manufacturer: | International Harvester |
| Type: | Utility tractor |
| Factory: | Neuss, Germany |
Variants | |
| utility | |
| narrow |
International Harvester 733 Power | |
| Engine: | 59 hp 44.0 kW |
Mechanical | |
| Chassis: | 4x2 2WD |
| 4x4 MFWD 4WD | |
| Differential lock: | mechanical rear |
| 2WD Steering: | manual |
| 4WD Steering: | power |
| Brakes: | hydraulic disc |
| Cab: | Four-post ROPS. Cab optional with heat. |
| Transmissions: | 8-speed |
| 16-speed | |
| 16-speed creeper | |
Capacity | |
| Fuel: | 15.85 gal 60.0 L |
| Hydraulic system: | 3.2 gal 12.1 L |
Hydraulics | |
| Capacity: | 3.2 gal 12.1 L |
| Pump flow: | 8.5 gpm 32.2 lpm |
Tractor hitch | |
| Rear Type: | II |
| Rear lift: | 4630 lbs 2100 kg |
Power Take-off (PTO) | |
| Rear PTO: | independent |
| Rear RPM: | 540 |
Electrical | |
| Charging system: | alternator |
| Charging amps: | 33 |
| Charging volts: | 14 |
| Battery volts: | 12 |
| Battery AH: | 88 |
Engine Detail | |
| International Harvester D-206 | |
| diesel | |
| 4-cylinder | |
| liquid-cooled | |
| Displacement: | 206.4 ci 3.4 L |
| Bore/Stroke: | 3.875x4.375 inches 98 x 111 mm |
| Power: | 59 hp 44.0 kW |
| Fuel system: | direct injection |
| Air cleaner: | dry |
| Rated RPM: | 2180 |
| Torque: | 154 lb-ft 208.8 Nm |
| Torque RPM: | 1600 |
| Starter volts: | 12 |
| Oil capacity: | 9.5 qts 9.0 L |
| Coolant capacity: | 18.5 qts 17.5 L |
Dimensions | |
| 2WD Wheelbase: | 86.2 inches 218 cm |
| 4WD Wheelbase: | 84.6 inches 214 cm |
| Length: | 141.5 inches 359 cm |
| Width: | 64.6 inches 164 cm |
| 2WD Height (steering wheel): | 60 inches 152 cm |
| 4WD Height (steering wheel): | 69.8 inches 177 cm |
| Clearance (front axle): | 20.9 inches 53 cm |
| 2WD Front tread: | 48.5 to 69.7 inches 123 to 177 cm |
| 4WD Front tread: | 54.1 to 63.9 inches 137 to 162 cm |
| 2WD Rear tread: | 56.2 to 74.8 inches 142 to 189 cm |
| 4WD Rear tread: | 50.4 to 74.8 inches 128 to 189 cm |
