Iseki TF223

Type: Compact Utility Tractors

Contents:

Production

Manufacturer:Iseki
Type:Compact Utility tractor

Iseki TF223 Power

Engine:21.7 hp 16.2 kW
PTO (claimed):19.4 hp 14.5 kW

Mechanical

Chassis:4x4 MFWD 4WD
Cab:Two-post folding ROPS.
Transmission:9-speed

Tractor hitch

Rear Type:0

Power Take-off (PTO)

Rear RPM:540 (1.375)
Engine RPM:522@2500 818@2500 1265@2500

Electrical

Ground:negative
Battery volts:12

Engine Detail

E3CE-B
diesel
3-cylinder
liquid-cooled
Displacement:87.2 ci 1.4 L
Bore/Stroke:3.35x3.31 inches 85 x 84 mm
Power:21.7 hp 16.2 kW
Rated RPM:2500
Starter:electric
Starter volts:12

Transmission

Gears:9 forward and 3 reverse

Dimensions

Wheelbase:61 inches 154 cm
Length:113.8 inches 289 cm
Width:46.5 inches 118 cm
Height:76.2 inches 193 cm
Weight:1929 lbs 874 kg
Ground clearance:13.2 inches 33 cm
Front tread:37.8 inches 96 cm
Rear tread:34.7/40.8 inches 88/103 cm
