International Harvester TD-340
Contents:
Production | |
| Manufacturer: | International Harvester |
| Type: | Agricultural Crawler tractor |
| Factory: | Melrose Park, Illinois, USA |
Variants | |
| gasoline |
International Harvester TD-340 Power | |
| Drawbar (claimed): | 33 hp 24.6 kW |
| Belt (claimed): | 40 hp 29.8 kW |
| Drawbar (tested): | 31.6 hp 23.6 kW |
| Belt (tested): | 39.8 hp 29.7 kW |
Mechanical | |
| Chassis: | crawler |
| Transmission: | 5-speed |
TD-340 Serial Numbers | |
| Location: | instrument panel |
| 1959: | 501 |
| 1960: | 1979 |
| 1961: | 4344 |
| 1962: | 5449 |
| 1963: | 6397 |
| 1964: | 7338 |
| 1965: | 8525 |
Engine Detail | |
| International Harvester | |
| diesel | |
| 4-cylinder | |
| liquid-cooled vertical L-head | |
| Displacement: | 166 ci 2.7 L |
| Bore/Stroke: | 3.6875x3.875 inches 94 x 98 mm |
| Compression: | 19.7:1 |
| Rated RPM: | 2000 |
| Starter volts: | 12 |
Transmission | |
| Gears: | 5 forward and 1 reverse |
Dimensions | |
| Length: | 125 inches 317 cm |
| Width: | 58 inches 147 cm |
| Height: | 60.3 inches 153 cm |
| Weight: | 5,800 lbs 2630 kg |
