International Harvester 834

Production: 1972 - 1974

Production
Manufacturer:	International Harvester
Type:	Row-Crop tractor

International Harvester 834 Power
Engine (gross):	81.8 hp 61.0 kW
Engine (net):	73.8 hp 55.0 kW
PTO (claimed):	69.7 hp 52.0 kW

Mechanical
Chassis:	4x2 2WD
4x4 MFWD 4WD
Final drives:	pllanetary
Differential lock:	mechanical rear
Steering:	power
Brakes:	disc
Transmissions:	8-speed
12-speed

Tractor hitch
Rear Type:	II

Power Take-off (PTO)
Rear PTO:	independent
Rear RPM:	540/1000

Engine Detail
International Harvester D-246
diesel
4-cylinder
liquid-cooled
Displacement:	246.1 ci 4.0 L
Bore/Stroke:	3.94x5.06 inches 100 x 129 mm
Power (gross):	81.8 hp 61.0 kW
Fuel system:	direct injection
Compression:	16:1
Rated RPM:	2300
Torque:	193.8 lb-ft 262.8 Nm
Torque RPM:	1600
Starter:	electric
Starter volts:	12
Oil capacity:	9.5 qts 9.0 L
Coolant capacity:	20.6 qts 19.5 L

Dimensions
Wheelbase:	83.5 inches 212 cm
2WD Length:	131.5 inches 334 cm
4WD Length:	136.6 inches 346 cm
Width:	74.4 inches 188 cm
Height (steering wheel):	65 inches 165 cm
2WD Weight:	7518 lbs 3410 kg
4WD Weight:	8289 lbs 3759 kg
2WD Front tread:	51.6 to 70.1 inches 131 to 178 cm
4WD Front tread:	59.1 inches 150 cm
Rear tread:	57.5 to 77.2 inches 146 to 196 cm
