International Harvester 483

Production: 1982 - 1984

Production
Distributor:	International Harvester
Manufacturer:	Komatsu
Type:	Utility tractor
Factory:	Japan
Original price:	$13,900 (1984 )

International Harvester 483 Power
Engine:	46 hp 34.3 kW
PTO (claimed):	42 hp 31.3 kW

Mechanical
Chassis:	4x2 2WD
4x4 MFWD 4WD
Steering:	hydrostatic power
Brakes:	hydraulic wet disc
Cab:	ROPS and canopy optional
Transmission:	8-speed

Capacity
Fuel:	15.1 gal 57.2 L
Hydraulic system:	8.5 gal 32.2 L

Hydraulics
Capacity:	8.5 gal 32.2 L
Pressure:	2500 psi 172.4 bar
Total flow:	6.4 gpm 24.2 lpm

Tractor hitch
Rear Type:	I/II
Rear lift (at ends):	3,307 lbs 1500 kg

Power Take-off (PTO)
Rear PTO:	independent
Rear RPM:	540

Electrical
Charging system:	alternator
Charging amps:	35
Battery volts:	12

Engine Detail
Nissan SD25
diesel
4-cylinder
liquid-cooled
Displacement:	151.8 ci 2.5 L
Bore/Stroke:	3.50x3.94 inches 89 x 100 mm
Power:	46 hp 34.3 kW
Rated RPM:	2400
Torque:	104.3 lb-ft 141.4 Nm
Starter volts:	12
Oil capacity:	6 qts 5.7 L
Coolant capacity:	8.4 qts 7.9 L

Transmission
Gears:	8 forward and 2 reverse
Oil capacity:	34 qts 32.2 L

Dimensions
Wheelbase:	76.8 inches 195 cm
Length:	118.3 inches 300 cm
Width:	65.2 inches 165 cm
Height (steering wheel):	61.4 inches 155 cm
Height (exhaust):	87.8 inches 223 cm
Shiping weight:	3,550 lbs 1610 kg (2WD)
3,991 lbs 1810 kg (4WD)
Ground clearance:	15.4 inches 39 cm (2WD)
15.9 inches 40 cm (4WD)
Front tread:	48 to 75.7 inches 121 to 192 cm
Rear tread:	47.6 to 76.1 inches 120 to 193 cm
