International Harvester 474

Production: 1972 - 1974

Production
Manufacturer:	International Harvester
Type:	Utility tractor
Factory:	Doncaster, England

International Harvester 474 Power
Engine:	62 hp 46.2 kW
PTO (claimed):	49 hp 36.5 kW

Mechanical
Chassis:	4x2 2WD
Steering:	power
Brakes:	wet disc
Cab:	Open operator station. Cab available.
Transmission:	8-speed synchromesh

Hydraulics
Pump flow:	11.9 gpm 45.0 lpm

Tractor hitch
Rear lift:	3969 lbs 1800 kg

Power Take-off (PTO)
Rear RPM:	540/1000

Engine Detail
International Harvester D206
diesel
4-cylinder
liquid-cooled
Displacement:	206 ci 3.4 L
Bore/Stroke:	3.875x5.06 inches 98 x 129 mm
Power:	62 hp 46.2 kW
Rated RPM:	2200
Starter type:	electric

Transmission
Type:	synchromesh
Gears:	8 forward and 4 reverse

Dimensions
Wheelbase:	84.5 inches 214 cm
Length:	135 inches 342 cm
Height (hood):	57 inches 144 cm
Height (cab):	91 inches 231 cm
Weight:	5854 lbs 2655 kg
Front tread:	52 to 80 inches 132 to 203 cm
Rear tread:	52 to 76 inches 132 to 193 cm
