International Harvester 454
Type: Utility Tractors
Contents:
Production | |
| Manufacturer: | International Harvester |
| Type: | Utility tractor |
| Factory: | Doncaster, England |
| Original price: | $4,640 (1973 ) |
International Harvester 454 Power | |
| Engine: | 50 hp 37.3 kW |
| Drawbar (claimed): | 35 hp 26.1 kW |
| PTO (claimed): | 40 hp 29.8 kW |
| Drawbar (tested): | 35.35 hp 26.4 kW |
| PTO (tested): | 40.86 hp 30.5 kW |
Mechanical | |
| Chassis: | 4x2 2WD |
| Steering: | power |
| Brakes: | independent hydraulic wet disc |
| Cab: | Open operator station. |
| Transmission: | 8-speed sliding gear |
Hydraulics | |
| Pump flow: | 11.9 gpm 45.0 lpm |
Tractor hitch | |
| Rear Type: | I |
| Rear lift: | 3307 lbs 1500 kg |
Power Take-off (PTO) | |
| Rear PTO: | independent |
| Rear RPM: | 540/1000 |
454 Serial Numbers | |
| Location: | Clutch housing, left side of tractor. |
| 1970: | 501 |
| 1971: | 508 |
| 1972: | 4908 |
| 1973: | 8064 |
Electrical | |
| Charging system: | alternator-generator |
| Charging amps: | 32 |
| Batteries: | 1 (gas) |
| 2 (diesel) | |
| Battery volts: | 12 (gas) |
| 6 (diesel) | |
| Battery AH: | 40 (gas) |
| 135 (diesel) | |
Engine Detail | |
| International Harvester C-157 | |
| gasoline | |
| 4-cylinder | |
| liquid-cooled | |
| Displacement: | 157 ci 2.6 L |
| Bore/Stroke: | 3.375x4.39 inches 86 x 112 mm |
| Power: | 50 hp 37.3 kW |
| Air cleaner: | dry |
| Compression: | 7.5:1 |
| Rated RPM: | 2200 |
| Starter volts: | 12 |
| Oil capacity: | 7 qts 6.6 L |
| Coolant capacity: | 11.5 qts 10.9 L |
Transmission | |
| Type: | sliding gear |
| Gears: | 8 forward and 4 reverse |
| Oil capacity: | 36 qts 34.1 L |
| Fours synchronized gears in each of high, low, and reverse ranges. | |
Dimensions | |
| Wheelbase: | 75 inches 190 cm |
| Length: | 131.9 inches 335 cm |
| 133 inches 337 cm (with 3-point) | |
| Width: | 66 inches 167 cm (min) |
| Height (steering wheel): | 55 inches 139 cm |
| Ground clearance: | 10 inches 25 cm |
