International Harvester 1246

Production: 1972 - 1980

Contents:

Production

Manufacturer:International Harvester
Factory:Neuss, Germany

International Harvester 1246 Power

Engine:122 hp 91.0 kW

Mechanical

Chassis:4x2 2WD
4x4 MFWD 4WD
Transmissions:12-speed
16-speed

Hydraulics

Pump flow:10.6 gpm 40.1 lpm

Tractor hitch

Rear lift:8158 lbs 3700 kg

Power Take-off (PTO)

Rear RPM:540, 1000

Engine Detail

International Harvester
turbocharged diesel
6-cylinder
liquid-cooled
Displacement:358 ci 5.9 L
Bore/Stroke:3.875x5.0625 inches 98 x 129 mm
Power:122 hp 91.0 kW
Rated RPM:2200

Dimensions

Wheelbase:100.79 inches 256 cm
Length:165.35 inches 419 cm
Height:107.09 inches 272 cm
2WD Weight:9481 lbs 4300 kg
4WD Weight:10694 lbs 4850 kg
