International Harvester 1046

Production: 1971 - 1978

Production
Manufacturer:	International Harvester
Type:	Row-Crop tractor
Factory:	Neuss, Germany

International Harvester 1046 Power
Engine (gross):	108.5 hp 80.9 kW
PTO (claimed):	93.9 hp 70.0 kW

Mechanical
Chassis:	4x2 2WD
4x4 MFWD 4WD
Steering:	power
Transmissions:	12-speed
16-speed

Hydraulics
Pump flow:	10 gpm 37.9 lpm

Tractor hitch
Rear Type:	II
Rear lift:	6615 lbs 3000 kg

Power Take-off (PTO)
Rear RPM:	540/1000

Engine Detail
International Harvester D-358
diesel
6-cylinder
liquid-cooled
Displacement:	358 ci 5.9 L
Bore/Stroke:	3.875x5.0625 inches 98 x 129 mm
Power (gross):	108.5 hp 80.9 kW
Compression:	16:1
Rated RPM:	2100
Starter volts:	12
Oil capacity:	14.8 qts 14.0 L
Coolant capacity:	28.5 qts 27.0 L

Dimensions
Wheelbase:	102 inches 259 cm
Length:	154.7 inches 392 cm
Width:	81.9 inches 208 cm
Height (hood):	59.8 inches 151 cm
2WD Weight:	8929 lbs 4050 kg
4WD Weight:	9700 lbs 4399 kg
Ground clearance:	15.4 inches 39 cm
Front tread:	59.5 to 71.7 inches 151 to 182 cm
Rear tread:	63.8 to 83.5 inches 162 to 212 cm
