IMT 542

Production: 1986

Production
Manufacturer:	IMT

IMT 542 Power
Engine:	42 hp 31.3 kW

Mechanical
Chassis:	4x2 2WD
4x4 MFWD 4WD optional
Steering:	power optional
Transmissions:	6-speed
10-speed

Hydraulics
Total flow:	4.8 gpm 18.2 lpm

Tractor hitch
Rear lift:	3087 lbs 1400 kg

Power Take-off (PTO)
Rear RPM:	540

Engine Detail
M 33/T
diesel
3-cylinder
Displacement:	152.6 ci 2.5 L
Bore/Stroke:	3.60x5.00 inches 91 x 127 mm
Power:	42 hp 31.3 kW
Rated RPM:	2250

Dimensions
Wheelbase:	78.3 inches 198 cm
Length:	128.3 inches 325 cm
Height:	90.2 inches 229 cm
Weight:	4,818 lbs 2185 kg
