Hurlimann H-1500 SX

Production: 1998 - 2004

Contents:

Production

Manufacturer:Hurlimann

Hurlimann H-1500 SX Power

Engine:150 hp 111.9 kW

Mechanical

Chassis:4x2 2WD
4x4 MFWD 4WD optional
Steering:hydrostatic power
Transmission:18-speed

Hydraulics

Pump flow:27.2 gpm 103.0 lpm

Tractor hitch

Rear lift:18,963 lbs 8601 kg

Power Take-off (PTO)

Rear RPM:540, 1000

Engine Detail

SAME
turbo diesel
6-cylinder
Displacement:366.12 ci 6.0 L
Bore/Stroke:4.1338x4.5472 inches 105 x 115 mm
Power:150 hp 111.9 kW
Rated RPM:2350
Torque:481.7 lb-ft 653.2 Nm
Torque RPM:1450

Transmission

Gears:18 forward and reverse

Dimensions

Wheelbase:108.27 inches 275 cm
Length:183.9 inches 467 cm
Height:113.4 inches 288 cm
Weight:13,450 lbs 6100 kg
