Lamborghini Champion 150
Type: Row-crop Tractors
Contents:
Production | |
| Manufacturer: | Lamborghini |
| Type: | Row-Crop tractor |
Lamborghini Champion 150 Power | |
| Engine: | 150 hp 111.9 kW |
Mechanical | |
| Chassis: | 4x4 MFWD 4WD |
| Differential lock: | electro-hydraulic front and rear |
| Steering: | power |
| Brakes: | hydraulic wet disc |
| Trailer brakes: | hydraulic |
| Cab: | Cab standard with air-conditioning. |
| Transmissions: | 18-speed 9-speed power shift |
| 27-speed creeper | |
Hydraulics | |
| Type: | open center |
| load-sensing*Optional | |
| Valves: | 8*Optional |
| Pump flow: | 19.3 gpm 73.1 lpm (open) |
| 27.2 gpm 103.0 lpm (load-sensing) | |
Tractor hitch | |
| Rear lift: | 15432 lbs 6999 kg |
| 18960 lbs 8600 kg *With optional lift cylinders. | |
| Front lift: | 8818 lbs 3999 kg *Optional |
Power Take-off (PTO) | |
| Rear PTO: | independent |
| Clutch: | electro-hydraulic wet disc |
| Rear RPM: | 540/1000 |
| 540E/1000 | |
| Front PTO: | independent*Optional |
| Clutch: | electro-hydraulic |
| Front RPM: | 1000 |
Electrical | |
| Charging system: | alternator |
Engine Detail | |
| SDF 1000.6 WTI 3V | |
| turbocharged intercooled diesel | |
| 6-cylinder | |
| liquid-cooled | |
| Displacement: | 366.1 ci 6.0 L |
| Bore/Stroke: | 4.134x4.54 inches 105 x 115 mm |
| Power: | 150 hp 111.9 kW |
| Rated RPM: | 2350 |
| Torque: | 481.7 lb-ft 653.2 Nm |
| Torque RPM: | 1450 |
| Starter type: | electric |
Dimensions | |
| Wheelbase: | 108.3 inches 275 cm |
| Length: | 183.9 inches 467 cm *Length with three-point linkage |
| Width: | 96.5 inches 245 cm *Minimum width |
| Height (hood): | 61.4 inches 155 cm |
| Height (cab): | 113.4 inches 288 cm |
| Weight: | 13448 lbs 6100 kg |
| Ground clearance: | 20.5 inches 52 cm |
| Front tread: | 71.7 to 100.8 inches 182 to 256 cm |
| Rear tread: | 76 to 92.5 inches 193 to 234 cm |
