Ford 960
Type: Row-crop Tractors
Contents:
Production | |
| Manufacturer: | Ford |
| Type: | Row-Crop tractor |
| Factory: | Highland Park, Michigan, USA |
| Original price: | $2,561 (1957) |
Variants | |
| utility chassis | |
| four-speed | |
| five-speed | |
| five-speed, live PTO |
Ford 960 Power | |
| Belt (claimed): | 40 hp 29.8 kW |
| Plows: | 3 (14-inch) |
| Drawbar (tested): | 38.40 hp 28.6 kW |
| Belt (tested): | 46.27 hp 34.5 kW |
Mechanical | |
| Chassis: | 4x2 2WD |
| Steering: | manual |
| power assist optional | |
| Brakes: | differential mechanical expanding shoe |
| Cab: | Open operator station. |
| Transmission: | 5-speed unsynchronized gear |
Tractor hitch | |
| Rear Type: | I |
| Rear lift: | 1,250 lbs 567 kg |
Power Take-off (PTO) | |
| Rear PTO: | live |
| Rear RPM: | 540 |
960 Serial Numbers | |
| Location: | Serial number stamped into the starter mount on the left side of the engine. |
Electrical | |
| Ground: | positive |
| Charging system: | generator |
| Charging amps: | 20 |
| Battery volts: | 6 |
Engine Detail | |
| Ford EAF | |
| gasoline | |
| 4-cylinder 8-valve | |
| liquid-cooled vertical inline | |
| Displacement: | 172 ci 2.8 L |
| Bore/Stroke: | 3.90x3.60 inches 99 x 91 mm |
| Air cleaner: | oil bath |
| Compression: | 6.75:1 |
| Rated RPM: | 2200 |
| Firing order: | 1-2-4-3 |
| Starter volts: | 6 |
| Coolant capacity: | 15 qts 14.2 L |
Transmission | |
| Transmission: | Ford |
| Type: | unsynchronized gear |
| Gears: | 5 forward and 1 reverse |
| Clutch: | dry disc |
Dimensions | |
| Wheelbase: | 85.3 inches 216 cm |
| Length: | 132.6 inches 336 cm |
| Height: | 65.8 inches 167 cm |
| Ground clearance: | 27.9 inches 70 cm |
| Front tread: | 8.3 to 16.3 inches 21 to 41 cm |
| Rear tread: | 56 to 80 inches 142 to 203 cm |
