Ford 5600
Type: Row-crop Tractors
Contents:
Production | |
| Manufacturer: | Ford |
| Type: | Row-Crop tractor |
| Original price: | $26,000 (1981 ) |
Ford 5600 Power | |
| Engine (gross): | 69 hp 51.5 kW |
| Engine (net): | 65 hp 48.5 kW |
| PTO (claimed): | 60.5 hp 45.1 kW |
| Drawbar (tested): | 50.09 hp 37.4 kW |
| PTO (tested): | 60.49 hp 45.1 kW |
Mechanical | |
| Chassis: | 4x2 2WD |
| 4x4 MFWD 4WD | |
| Final drives: | inboard planetary |
| Differential lock: | mechanical rear |
| Steering: | power |
| Brakes: | differential mechanical wet disc |
| Cab: | Open operator station. Two-post ROPS available. Cab optional with available heat and air-conditioning. |
| Transmissions: | 16-speed two-speed power shift |
| 8-speed gear | |
Hydraulics | |
| Pressure: | 2100 psi 144.8 bar |
| Valves: | 1 or 2 |
| Pump flow: | 9.7 gpm 36.7 lpm |
Tractor hitch | |
| Rear Type: | II |
| Control: | top-link draft sensing |
| Rear lift: | 3340 lbs 1515 kg |
Power Take-off (PTO) | |
| Rear PTO: | independent |
| Rear RPM: | 540 (1.375) |
| 540/1000*Optional | |
| Engine RPM: | 540@1900 |
5600 Serial Numbers | |
| 1975: | C450700 |
| 1976: | C490300 |
| 1977: | C527300 |
| 1978: | C560500 |
| 1979: | C595800 |
| 1980: | C635700 |
| 1981: | C660700 |
Electrical | |
| Ground: | negative |
| Charging system: | alternator |
| Charging amps: | 32 |
| 51*Optional on open station tractor, standard with cab. | |
| Battery volts: | 12 |
| Battery AH: | 128 |
Engine Detail | |
| Ford | |
| diesel | |
| 4-cylinder | |
| liquid-cooled | |
| Displacement: | 233 ci 3.8 L |
| Bore/Stroke: | 4.20x4.20 inches 107 x 107 mm |
| Power (gross): | 69 hp 51.5 kW |
| Air cleaner: | oil bath |
| Compression: | 16.3:1 |
| Rated RPM: | 2100 |
| Torque: | 182 lb-ft 246.8 Nm |
| Torque RPM: | 1400 |
| Starter volts: | 12 |
| Oil capacity: | 9 qts 8.5 L |
| Coolant capacity: | 13 qts 12.3 L *Capacity without cab heater or air-conditioning. |
Dimensions | |
| Wheelbase: | 87.5 inches 222 cm |
| Length: | 141.6 inches 359 cm |
| Width: | 72.2 inches 183 cm *Width over fenders with factory cab. |
| Clearance (front axle): | 18 inches 45 cm |
| Front tread: | 52.5 to 80.5 inches 133 to 204 cm |
| Rear tread: | 52 to 80 inches 132 to 203 cm |
| Rear tread: | 66 to 90 inches 167 to 228 cm *Power-adjust wheels. |
