Ford 5530
Type: High-clearance Tractors
Contents:
Production | |
| Manufacturer: | Ford |
| Type: | High-Clearance tractor |
| Original price: | $25,300 (1996 ) |
Ford 5530 Power | |
| PTO (claimed): | 62 hp 46.2 kW |
Mechanical | |
| Chassis: | 4x2 2WD |
| 4x4 MFWD 4WD | |
| Brakes: | disc |
| Cab: | Four-post ROPS. |
| Transmissions: | 12-speed partially synchronized |
| 20-speed synchromesh | |
Hydraulics | |
| Type: | open center |
| Valves: | 1 to 3 |
| Pump flow: | 11 gpm 41.6 lpm |
Tractor hitch | |
| Rear Type: | II |
| Rear lift: | 5194 lbs 2355 kg |
Power Take-off (PTO) | |
| Rear PTO: | independent |
| Rear RPM: | 540/1000 |
Electrical | |
| Ground: | negative |
| Charging system: | alternator |
| Charging amps: | 33 |
| Battery volts: | 12 |
Engine Detail | |
| Fiat 8045.06 | |
| diesel | |
| 4-cylinder | |
| liquid-cooled | |
| Displacement: | 220 ci 3.6 L |
| Bore/Stroke: | 3.937x4.527 inches 100 x 115 mm |
| Rated RPM: | 2500 |
| Starter: | electric |
| Starter volts: | 12 |
| Oil capacity: | 12 qts 11.4 L |
Dimensions | |
| 2WD Wheelbase: | 82.8 inches 210 cm |
| 4WD Wheelbase: | 80.7 inches 204 cm |
| 2WD Length: | 148.5 inches 377 cm |
| 4WD Length: | 161.5 inches 410 cm |
| Height (ROPS): | 109 inches 276 cm |
| 2WD Weight: | 5689 lbs 2580 kg |
| 4WD Weight: | 7290 lbs 3306 kg |
| 2WD Clearance (front axle): | 31.5 inches 80 cm |
| 4WD Clearance (front axle): | 25 inches 63 cm |
| 2WD Clearance (drawbar): | 25 inches 63 cm |
| 4WD Clearance (drawbar): | 25.7 inches 65 cm |
| 2WD Front tread: | 61 to 81 inches 154 to 205 cm |
| 4WD Front tread: | 66 to 86 inches 167 to 218 cm |
| 2WD Rear tread: | 56 to 76 inches 142 to 193 cm |
| 4WD Rear tread: | 56 to 74 inches 142 to 187 cm |
