Fiat 765C

Production: 1982 - 1984

Production
Manufacturer:	Fiat
Type:	Agricultural Crawler tractor

Fiat 765C Power
Engine:	77 hp 57.4 kW

Mechanical
Chassis:	crawler
Transmissions:	8-speed
16-speed

Power Take-off (PTO)
Rear RPM:	540/1000

Engine Detail
Fiat 8045.04
diesel
4-cylinder
liquid-cooled
Displacement:	224 ci 3.7 L
Bore/Stroke:	4.06x4.33 inches 103 x 110 mm
Power:	77 hp 57.4 kW
Rated RPM:	2500
Starter type:	electric

Dimensions
Length:	125.8 inches 319 cm
Width:	66.1 inches 167 cm
Height (exhaust):	87.4 inches 221 cm
Weight:	9039 lbs 4100 kg
Gauge:	51.2 inches 130 cm
